Laboratory Borate Affinity POCT Hba1c Analyser OEM ODM

HbA1c Test Analyzer Hemoglobin Detection Analysis LD-100 Poct HbA1c Fully Automatic Testing Analyzer

Intended Use

HbA1c Analyzer LD-100 is One Step HbA1c Testing Analyzer, it is intended for the content etermination of hemoglobin A1c (HbA1c) in human whole blood, It's a fully automatic HbA1c testing analyzer, one step operate process without extra instrument. LD-100 is very small and light than other analyzer in same type so it can be suitable for the detection of HbA1c in medical units at all levels.

Specifications

PRINCIPLE

• Uses the (borate affinity) fluorescent immunoturbidimetry
• Push a mixture containing a fluorescent borate conjugate into an integrated test cup and mix to dissolve sufficiently.
• The blood samples in the sample collector are then pushed into the buffer and mixed to release the hemoglobin from the red blood cells.
• The total concentration of hemoglobin depends on the initial reduced fluorescence signal.
• Fluorescent borate conjugates bind to glycosylated hemoglobin, and glycosylated hemoglobin is determined by detecting the decrease of fluorescent active ingredients.
• The percentage of glycosylated hemoglobin in total hemoglobin can be determined.

Feature

• One-Step Testing,Fully Automatic System
• Category of the test product: Laboratory
• Fast test speed and High Accuracy within 3 min
• Working environment: Standard
• Cv<3%, Excellent Correlation With HPLC
• Input power: <60VA
• Color touch screen just need to clik the screen and easy to read

Reliable

Use Step

• Place cartridge in analyzer
• Push bead into reagents
• Insert sample into cartridge

Performance Parameters

• Accuracy: Tested with the reference material as samples, and the relative deviation of the determination results of the analyzer should be within the range of ±8%.
• Precision:Samples with a concentration of 4.0%-6.5% are detected, sample coefficient of variation (CV) of the test results is not more than 3%.
• Linearity:In the range of 4%-16% of HbA1c, the linear correlation coefficientrof the test results should be no less than 0.9900.
• Stability:Within 8 hours after the instrument is turned on and stable, the relative deviation of the test results is not more than ±3%.

Analysis Interface

Click the Analysis button on the main interface to enter the sample detection program. For details, see 5.3 Sample Detection.

Certificated
